• WPC-632-Pi 4-CAM-5G

WPC-632-Pi 4-CAM-5G

Model : WPC-632-Pi 4-CAM-5G

Applications

• Raspbian Linux OS / GNU / Linux

• Multiple Serial Interfaces

• Powerful Computing capability

• On board 40 x GPIO

• 4, 8, 16, 32GB EMMC Flash ROM optional

System

CPU : ARM Cortex –A53 CPU , 1.2 GHz

RAM : 1 G Bytes SDRAM

ROM : 4G/ 8G/ 16G/ 32G Bytes EMMC Flash ROM (option)

Ethernet *1 (2nd LAN option)

  • Port Type : RJ-45 Connector
  • Speed : 10 /100 M bps ( Auto Detecting )
  • Protocol : ARP , IP , ICMP , UDP , TCP , HTTP , DHCP
  • Protocol PPPoE , DDNS , NTP , FTP , Telnet
  • Mode : TCP Server / TCP Client / UDP
  • Setup : HTTP Browser Setup (IE & Netscape) , Console
  • Security : Setup Password
  • Protection : Built-in 1.5KV Magnetic Isolation

Serial Ports *2

  • Port : RS -232 / 422 / 485 * 2 Ports ( Surge Protect )
  • Speed300 bps ~ 921.6 K bps
  • ParityNone , Odd , Even , Mark , Space
  • Data Bit5 , 6 , 7 , 8
  • Stop Bit : 1 , 2
  • RS-232 Pins : Rx , Tx , GND
  • RS-422 : Rx+ , Rx- , Tx+ , Tx- ( Surge Protect )
  • RS-485 : Data+ , Data- ( Surge Protect ) ( Over current protect )
  • 15KV ESD for all signals

Other Features

  • Digital Input / Output : GPIO * 16 Pins
  • HDMI for Video / Audio
  • SPI Interface * 1 on board
  • I2C Interface * 1 port
  • SD Interface : micro SD card ( for storage only )
  • USB ( Host * 3 port ) : for WiFi Dongle , Bluetooth Dongle, Memory Storage
  • USB ( Slave * 1, jumper select for Pi CM3 Initial Image Download )
  • RTC : Real Time Clock * 1
  • Buzzer * 1
  • Watch Dog Function
  • Mini-PCIE Connector (USB) - for 4G / WIFI / BLUETOOTH / LoRa )
  • LED Lamp : SYS, EMMC MEMORY R/W, LAN LINK, LAN TRANSMIT

Power

  • DC 9~32 V , 1000 mA 500mA@12V, support DC Jack & Terminal Input

Mechanical and Environment

  • Operating Temperature:-10 070
  • Storage Temperature : -2080
  • Dimensions : 200x120x30mm ( W * D * H )
  • Weight : 620 gm
  • Housing: metal

Warranty

  • Warranty period : 1 year.
