US-101-232

Model : US-101-232

1-Port USB To RS-232 Converter



• Plug & Play installation

• Built in 15KV ESD protection for signals

• Windows, MAC OS, Linux driver support

• Compact and User friendly Design

• Type A USB Connecor


Serial Interface

Port number : 1

Port Type : RS-232 x 1 Port ( DB9 )

Connector : Male DB9

RS-232 Speed : 300 bps ~ 921.6 Kbps

Parity : None , Odd , Even , Mark , Space

Data Bit : 5, 6 , 7 , 8

Stop Bit : 1 , 2

RS-232 : Rx , Tx , GND , RTS , CTS , DTR , DSR ,

Receive buffer 576 Bytes

Transmit buffer 640 Bytes

Flow Control : X-on / X-off or Hardware

Power

Input: USB Bus power, DC5V, 50mA

Driver Support

Windows 98SE/2000/XP/2003/VISTA/WIN 7/WIN 8

MAC OS OSX / OS9

Linux 2.4 / 2.6

USB Interface

Chipset : Silicon Lab CP2102

USB spec : USB 1.0, 1.1, 2.0

Connector : USB Type B

Baud Rates : Full speed 12Mbps

Regulatory Approval

FCC Part15 Class A

CE EN55022 Class A, EN55024

RoHS Compliance

Warranty 1 Year

Environment

Temperature : Operating: 0°C ~ 65°C (32°F ~ 149°F)

Storage: -20°C ~ 70°C (-4°F ~ 158°F)

Humidity : Operating: 10% ~ 95% non-condensing

Storage: 5% ~ 95% non-condensing

Dimension & Weight

Dimension 55 x 40 x 25 mm

Weight 35g
