Modbus-RS-232/422/485 To LoRaWAN

      LR-201-S-WAN : Modbus RS-232/422/485 To LoRaWAN
      Features : Auto polling Modbus RTU device Data To LoRaWAN Server
      CPU : Xtensa® 32-bit LX6 microprocessors 160M Hz
      RAM : 400K Bytes SRAM ; ROM : 380K Bytes Flash ROM
      Support : LoRaWAN 1.0.2

• LoRa : Semtech SX1262

• Freq. : ISM band 863 ~ 928MHz

• Receiver Sensitivity : -139 dBm

• Transmit Output Power : 22 dBm

• Deep Sleep Current : 10uA

• TX current < 140 mA@20 dbm , RX current < 10 mA

• Antenna : SMA Type , 2 dBi , changeable

• Distance : Up To 1500 Meters in free space

• Data Rate : 0.244 ~ 18.2K bps (LoRa)

• Application mode : Star

• Serial Port

• No.of Port : RS-232/422/485 * 1 port ( auto Detect )

• RS-232 : Rx , Tx , GND ( DB9 female )

• RS-422 : Tx+ , Tx-, Rx+ , Rx- (Surge Protect )

• RS-485 : Data+ , Data- (Surge Protect)

• Built –in RS-422/RS-485 Terminal Resistor

• Speed : 9600 bps〜115.2K bps

• Parity : None , Odd , Even

• Data Bit : 7, 8 / Stop Bit : 1 , 2

• Setup Tool : Windows Utility

• Power : DC 9 ~ 24V / 150ma @ 9V , 60ma @ 24V

• Led Lamp : SYS (green) , Rx(red) , Tx(green), Paired(Red)

• Environment : Operating Temperature: -10℃〜70℃

Storage Temperature : -20℃〜80℃

• Dimensions : 100 * 90 * 25 mm ( W * D * H )

• Weight : 150 gm ( not include power )
