• Fiber FS-120-SM

Fiber To RS-232/422/485 Single Mode or Multi-Mode Converter

Model : FS-220-SM / MM
 Full/half duplex, bidirectional transmission on RS-232/422/485
 Complied with EIA/TIA-232, EIA/TIA-422, EIA/TIA-485, EIA/TIA-574 and CCITT V.28 standards
 Dip switch to change the 2-wire or 4-wire mode.
 Supports DTE and DCE mode.
 Distance Up to 2KM with multimode fiber
 Distance Up to 20KM with single mode fiber
 Clear LED Indications
 MTBF > 50000 Hours
 Compact size: 68×101×30mm

 Full/half duplex, bidirectional transmission on RS-232/422/485

 Complied with EIA/TIA-232, EIA/TIA-422, EIA/TIA-485, EIA/TIA-574 and CCITT V.28 standards

 Dip switch to change the 2-wire or 4-wire mode.

 Supports DTE and DCE mode.

 Distance Up to 2KM with multimode fiber

 Distance Up to 20KM with single mode fiber

 Clear LED Indications

 MTBF > 50000 Hours

 Compact size: 68×101×30mm



SPECIFICATIONS

RS-232

Data Format

Asynchronous Serial Data

Data Rate

Up to 921.6Kbps

Connector Type

DB-9

RS-422/485

Data Format

Asynchronous Serial Data

Data Rate

Up to  921.6Kbps

Distance

1200m

Connector Type

5-pin Phoenix Connector with3.5mmPitch

Optical Interface

Single Mode Fiber

9/125μm

Wave length: 1310nm

Multimode Fiber

50/125, 62.5/125μm

Wave length: 850nm/1310nm

Connector Type

SC/ST/FC

Power

External power supply DC 12V ~ 48V, 1A, 0.5W@12VDC.

Environment

Ambient Temperature

-20 °C ~75°C

Storage Temperature

-20 °C ~85°C

Humidity

0 ~ 95% (Non-condensing)

Dimension

Cassette

60 x 100 x 30.5 mm (W x D x H)

Weight (Standalone)

80g




Product Image:

click above photo to get large view.

Data Sheet:

FS-220_DataSheet 202101a.pdf

User's Manual:

FS-220_quick_guide.pdf

Drivers:

upon request.
