• 4G LTE SMS 3 DI / 3 DO Controller by Cellular

4G LTE SMS 3 DI / 3 DO Controller by Cellular

Model : E-P332-4G-DIO33-SMS
• Support SMS Command via 4G
• Support Web Service (CGI) http Command via LAN port
• Auto Text Alert upon DI is triggered
• Support 3 DI / 3 DO
• Digital IO Controlled by TCP Socket
• Support TCP server
• Web Browser Configuration

4G LTE SMS 3DI/3DO Control by Cellular

• Support SMS Command via 4G
• Support Web Service (CGI) http Command via LAN port
• Auto Text Alert upon DI is triggered
• Support 3 DI / 3 DO
• Digital IO Controlled by TCP Socket
• Support TCP server
• Web Browser Configuration

System

CPU :  RISC CPU, 16 bits, 100 MHz,

RAM :  2MB Internal SDRAM

ROM :  256KB Flash ROM

Watchdog :  Built in H/W Watchdog timer



4G (for SMS only)

Five-Band: FDD-LTE B1/B3/B7/B8/B20

Dual-Band :  TDD-LTE B38/B40

Dual-Band: UMTS/HSDPA/HSPA+ B1/B8

Dual-Band GSM/GPRS/EDGE 900/1800 Mhz


LAN (for configuration only)

Port number:  1, RJ45

Speed :  10/100Mbps  Auto MSI/MDI-x

Protection :  Built in 1.5KV magnetic isolation


Software Features

Protocol :  TCP/IP, UDP, DHCP, Telnet, DNS, HTTP

OS Supported :  Win 2000/2003/XP/Vista/Win 7/Win 8

Configuration :  Window Utility, Web Browser


Operation Features

TCP/UDP Server and Client mode

Web Interface with User and Password protected

Support Virtual COM


LED

RXD/TXD/ACT

IN1/IN2/IN3

OUT1/OUT2/OUT3




Power

Input :  DC 9 ~24V, 500mA, 350mA@12VDC

Connector :  DC Jack & 2-pin terminal block


Dimensions

106.5 x115 x28mm


Serial Interface

Port number :  1

Port Type :  RS-232 or RS-422/485 1 port S/W selectable

Connector :  Male DB9 / 5-pin Terminal Block

Speed :  110 bps ~ 230.4 Kbps

Parity :  None , Odd , Even , Mark , Space

Data Bit :  5, 6 , 7 , 8

Stop Bit :  1 , 2

Protection :  RS-422/485 Surge Protection

  Built in 15KV ESD protection for all signals


Digital I/O

Digital Input :  3, support peer to peer

Digital Output :  3, support peer to peer

DO :  Relay Mode (Max. voltage DC 30V, 1A)


Environment

Temperature :  Operating:  0°C ~ 65°C (32°F ~ 149°F)

                        Storage: -20°C ~ 70°C (-4°F ~ 158°F)

Humidity :  Operating:  5% ~ 95% non-condensing

                  Storage:  5% ~ 95% non-condensing


Warranty   1 Year
